BL-580

◆UHF550-980MHz frequency band, PLL frequency synthesis phase-locked loop technology, adjustable frequency, adjustable transmit power, avoid interference frequency

◆Integrated bus control of the central processing unit CPU, with digital LCD interface display, easy operation and outstanding performance.

◆Multi-stage narrow-band high-frequency and intermediate-frequency selective frequency filtering is adopted to fully eliminate interference signals.

◆With audio compression and expansion technology, the noise is greatly reduced and the dynamic range is increased.

◆It has a function of reducing the howling suppression to reduce the whistle.

◆The receiver adopts multi-stage high-frequency amplification and has extremely high sensitivity.

◆Multiple noise monitoring circuit, specially designed to lock the TONE-LOCK system, which has unparalleled anti-jamming characteristics.

◆Excellent quality and excellent parts are selected to make the sound quality of this unit extremely excellent.

◆The maximum use range of air is more than 100 meters, and the ideal empty space is 50 meters.

BL-580 receiver

◆Carrier frequency: 550-980MHz (adjustable)

◆Power adapter voltage: AC110V-230V 50Hz/60Hz (please use the chassis and power adapter)

◆DC input voltage: DC12.8V 1500mA

◆Power consumption: 13W

◆S / N signal to noise ratio:≥105dB

◆T.H.D distortion: <0.5%

◆Frequency response: 40Hz-18KHz

BL-580 transmitter

◆Carrier frequency: 550-980MHz (adjustable)

◆Transmit power: high power file: 10dBm, low power file: 5dBm

◆Input audio modulation signal selection: MIC IN condenser microphone input (internal power supply) LINE IN audio line input

◆Modulation method: FM

◆Maximum modulation:±45KHz

◆Higher harmonics: 60dB or more below the main wave reference

◆Use battery voltage: 3V (2 AA1.5V alkaline batteries or high capacity AA1.2V-1800mAh rechargeable batteries)

◆Continuous use time: 8 hours

Bl560

◆UHF550-980MHz frequency band is applied, PLL frequency synthesis phase-locked loop technology is applied, the frequency is adjustable, the transmission power is adjustable, and the interference frequency is avoided.

◆Integrated bus control of the central processing unit CPU, with digital LCD interface display, easy operation and outstanding performance.

◆Multi-stage narrow-band high-frequency and intermediate-frequency selective frequency filtering is adopted to fully eliminate interference signals.

◆With audio compression and expansion technology, the noise is greatly reduced and the dynamic range is increased.

◆It has a function of reducing the howling suppression to reduce the whistle.

◆The receiver adopts multi-stage high-frequency amplification and has extremely high sensitivity.

◆Multiple noise monitoring circuit, specially designed to lock the TONE-LOCK system, which has unparalleled anti-jamming characteristics.

◆Excellent quality and excellent parts are selected to make the sound quality of this unit extremely excellent.

◆The maximum use range of air is more than 100 meters, and the ideal empty space is 50 meters.

BL-560 receiver

◆Carrier frequency: 550-980MHz (adjustable)

◆Power adapter voltage: AC110V-230V 50Hz/60Hz (please use the chassis and power adapter)

◆DC input voltage: DC12.8V 1500mA

◆Power consumption: 13W

◆S / N signal to noise ratio:≥105dB

◆T.H.D distortion: <0.5%

◆Frequency response: 40Hz-18KHz

BL-560 transmitter

◆Carrier frequency: 550-980MHz (adjustable)

◆Transmit power: high power file: 10dBm, low power file: 5dBm

◆Input audio modulation signal selection: MIC IN condenser microphone input (internal power supply) LINE IN audio line input

◆Modulation method: FM

◆Maximum modulation:±45KHz

◆Higher harmonics: 60dB or more below the main wave reference

◆Use battery voltage: 3V (2 AA1.5V alkaline batteries or high capacity AA1.2V-1800mAh rechargeable batteries)

◆Continuous use time: 8 hours
