4 Channel 120W to 500W High Efficiency Class D Power Amplifier

Category：Power Amplifier &Multi-channel AMP

BASIC INFO

4 Channel 120W to 500W High Efficiency Class D Power PA Digital Amplifier is class D power amplifier, which consist of 4 individual amplifiers. Optional rated power output include 120W, 240W, 350W and 500W. It’s designed in both tabletop and rack mount. Shinning feature is that it adopts tech. of power saving. And it’s with switching power so that the efficiency is up to 85%.

Thermogenesis is less than 55 degree. It could operate stably at severe working condition. 4 balanced line input is in type of phoenix. 4 RJ45 port is for remote power control, volume control and working status monitor. Speaker output is at 100V with individual volume control.

Indicators display signal, peak and protection status. Rational cooling system ensures the system to work under 55 degree. Complete protection is for overheat, overload and short.

Model	D-4120C	D-4240C	D-4350C	D-4500C
Rated Power Output	4x120W	4x240W	4x350W	4x500W
Speaker Output	100V
Input Sensitivity/Impedance	±385mV/20KΩ, balanced phoenix connector
Overload Electromotive Force	>11dB
Frequency Response	80Hz~16KHz (+1, -3dB)
S/N Ratio	≥85dB
THD	≤0.1% at 1KHz, 1/3 rated power
RJ45	Remote power control, volume control and status monitor
Indicators	Signal, peak, protection and power
Protection	Overheat, overload & short
Cooling	When Internal temp. reaches 55℃, the fan is turned on auto.
Power Consumption	600W	1200W	1750W	2250W
Power Supply	~110V/60Hz or ~230V/50Hz
Dimension	484 x 395 x 44mm
Weight	9.04Kg	10Kg	10.5Kg	11Kg
