BASIC INFO
Features:
1, the trapeze form allows mounting in various angles and corner. Little feet on the case bottom make it possible to place the speaker on a table,etc.
2, speaker mounting possible in-and outdoors.
3, There is a hidden impedance selector on the back panel with 3*100V, 4*70V and an 1*8 ohms position. A built-in high quality 100V matching transformer, ensure full quality of sound pressure and playback.
4, The speaker can be mounted horizontally or vertically. The grill can be taken off
Technical data
HYB128-4T
|
LU-S30B | LU-S40B |
Rate power |
30 W
|
40 W
|
Transformer tappings
|
30W-20W-10-5W(100V)
|
40W-20-10-5W(100V)
|
Frequency range
|
65Hz-20KHz
|
889dB
|
SPL (@1W/m)
|
85 dB
|
6.5 '' dual
|
Woofer
|
Dual 4''PP
|
1'' silk dome
|
Tweeter
|
1''silk dome
|
415*200*252mm
|
Dimension H*W*D(mm)
|
306*167*222mm
|
white or black
|
