BASIC INFO
Description
◆The new CLASS-TD ampl ifier , high efficiency, good sound qual ity, low temperatures.
◆High qual ity toroidal transformer.
◆High efficiency cool ing system.
◆Overload / overcurrent protection, over-temperature protection,short circuit protection, DC protection, distortion
protection and l imiter protection.
◆Smal l size and l ightweight .
◆SMT technology .
◆Using professional fever-grade capacitor.
Specification
| MODEL | TA6406 | TA6404 | TA6403 |
| Rated output power 8Ω | 600WX2 | 400WX2 | 300WX2 |
| Rated output power 4Ω | 1150WX2 | 750WX2 | 550WX2 |
| Frequency response | 20Hz~20KHz(+-0.3dB) | 20Hz~20KHz(+-0.3dB) | 20Hz~20KHz(+-0.3dB) |
| Signal-to-noise ratio | >98dB | >98dB | >98dB |
| Input sensitivity | 0.775V/1.0V/1.44V | 0.775V/1.0V/1.44V | 0.775V/1.0V/1.44V |
| THD | ≤0.05% | ≤0.05% | ≤0.05% |
| Input impedance | 20KΩ | 20KΩ | 20KΩ |
| Phase | ±10° | ±10° | ±10° |
| Net weight | 16KG | 14KG | 13KG |
| Package size mm | 483W×410D×89H | ||
| Package Package size mm | 560W×460D×165H | ||
