BASIC INFO
Description
◆The new CLASS-TD ampl ifier , high efficiency, good sound qual ity, low temperatures.
◆High qual ity toroidal transformer.
◆High efficiency cool ing system.
◆Overload / overcurrent protection, over-temperature protection,short circuit protection, DC protection, distortion
protection and l imiter protection.
◆Smal l size and l ightweight .
◆SMT technology .
◆Using professional fever-grade capacitor.
Specification
Model | M2 | M3 | M5 |
RMS 8ohms | 200W*2 | 300W*2 | 500W*2 |
Frequency response | 20-20KHz | ||
Sensitivity | >0.77v/1.0v/1.4v | ||
Work mode | stereo ,parallel | ||
THD | <0.05% | ||
S/N | >98db | ||
Damping factor | >1000(100hz) | ||
Slew rate | >20v/us | ||
Output Circuit | class-AB | ||
Net Weight | 13KG | ||
Product size | 483W*445D*88H | ||
Package size | 580W*495D*165H |
