BASIC INFO
Description
◆The new CLASS-TD ampl ifier , high efficiency, good sound qual ity, low temperatures.
◆High qual ity toroidal transformer.
◆High efficiency cool ing system.
◆Overload / overcurrent protection, over-temperature protection,short circuit protection, DC protection, distortion
protection and l imiter protection.
◆Smal l size and l ightweight .
◆SMT technology .
◆Using professional fever-grade capacitor.
Specification
| Rated output power 8Ω | 1200WX2 | 1000W | 800WX2 |
| Rated output power 4Ω | 2000WX2 | 1650W | 1350WX2 |
| Frequency response | 20Hz~20KHz(+-0.3dB) | 20Hz~20KHz(+-0.3dB) | 20Hz~20KHz(+-0.3dB) |
| Signal-to-noise ratio | ≥103dB | ≥103dB | ≥103dB |
| Input sensitivity | 0.775V/1.0V/1.44V | 0.775V/1.0V/1.44V | 0.775V/1.0V/1.44V |
| THD | ≤0.08% | ≤0.08% | ≤0.08% |
| Input impedance | 20KΩ | 20KΩ | 20KΩ |
| Bridage | 4000W | 3500W | 3000W |
| Phase | ±10° | ±10° | ±10° |
| Net weight | 31KG | 29KG | 27KG |
| Package size mm | 484W×460D×132H | ||
| Package Package size mm | 590W×600D×190H | ||
