BASIC INFO
Description
◆It use good aluminium frame.
◆low frequency is strong,HF Compression driver have high sensitivity.
◆Box with a 45 ° * 45 ° shape design,al lowing the singer to truly feel the sound reduction.
◆And clarity. Electro-acoustic engineers design rigorous points frequency circuit, with excel lent signal frequency processing
performance through the LMS,SmaartLive and other software.
Specification
| Model | SN152M | SN122M |
| System | 2-WAY FULL RANGE | 2-WAY FULL RANGE |
| Frequency response | 45Hz-18KHz | 50Hz-18KHz |
| Driver | LF:15"×1,HF:3"×1 | LF:12"×1,HF:1.73"×1 |
| Nomina limpedance | 8 Ohms | 8 Ohms |
| System sensitivity | 105dB | 95dB |
| Rated power | 450W | 300W |
| Peak power | 1800W | 1200w |
| Maximum SPL | 133dB | 120dB |
| coverange Angle | 80°+:50° | 80° +50° |
| Crossover mode | Internal crossovers | Internal crossovers |
| Suspension | On the floor or hung | On the floor or hung |
| Net weight | 37KG | 19.6KG |
| Size(mm) | 710W×576D×378H | 594W×484D×322H |
| Package size(mm) | 780W×651D×456H | 570W×405D×697H |
