BASIC INFO
Description
◆Aluminum al loy panel ,noble and elegant appearance.
◆Professional power ampl ifier circuit
◆8 professional anti-whistle function.
◆Short circuit protection, DC protection, overcurrent protection, overheating protection.
◆Microphone and music adjustments
◆Two signal output terminals, Two microphone input
◆4-way audio signal input.
Specification
| MODEL | K35 | K25 | K20 | K15 |
| Rated output power 8Ω | 350W*2 | 250W*2 | 200W*2 | 150W*2 |
| Rated output power 4Ω | 600W*2 | 450W*2 | 350W*2 | 250W*2 |
| Frequency response | Circuit:20Hz-20KHz, Mic: 50Hz-16KHz | |||
| Signal-to-noise ratio | >93db | |||
| THD | <0.05% | |||
| Damping coefficient | >1000(100Hz) | |||
| Input sensitivity | Circuit: 0.5V, Mic: 25MV | |||
| Resolution | >70db | |||
| Output Circuit | Class AB | |||
| Conversion rate | >20V/µs | |||
| Package size(W*D*H) mm | 430*290*120 | |||
