◆The semiconductor used is a world famous brand - ON Semiconductor;
◆Using special audio dedicated electrolytic capacitors, high grade and good sound;
◆SMT patch technology, high integration, product performance is more stable;
◆Intelligent stepless variable speed fan cooling system, ultra-quiet in low power or cold machine;
◆The perfect protection system is extremely stable in extreme environments, without accidents;
◆All adopts templating and compact design. It has precise and comprehensive protection system, beautiful and dynamic sound, stable and reliable performance, and exquisite appearance.
◆Professional perfect dynamic limiter can effectively protect your sound system without losing sound quality;
◆Applicable to medium and high-end professional markets, large installation markets, large discs, nightclubs, stadiums, cinemas, etc.
Specification
Model | A608 | A606 |
Rated Power(8Ω) | 800W*2; | 600W*2; |
Rated Power(4Ω) | 1350W*2; | 950W*2; |
Bridge Power(8Ω) | 2500W | 1800W |
Frequency Response | 20Hz-20KHz(+-0.3dB) | |
Sensitivity | 0.775V/1V/1.44V | |
Work Mode | Stereo/Merge/Bridge | |
S/Nor | ≥103dB. | |
THD | ≤0.08%. | |
Damping Ratio | ≥650; | |
Slew Rate | ≥25V/μs | |
Output Circuit | Class H+ | Class AB |
N./W. | 27KG | 22KG |
Size | 484W*460D*132H |
