BASIC INFO
Description
◆Intel l igent Variable Speed Heat Dissipation.
◆For a commom ampl ifier,when the music peak power is coming,aslo the voltage has not dynamic change,the common
ampl ifier wi l l not work or has no protection function.
◆But the SH series ampl ifier has the Dynamic l imit and cl ip function,the SH ampl ifier wi l l do the job perfectly.
◆The SH series has passed many test.The machine can continuous working without turn off for 96 hours in the terriable
situation including high and low temperation,shaking,droping and so on .
Specification
Model | H306 | H308 |
RMS 8ohms | 600W*2 | 800w*2 |
RMS 4ohms | 900W*2 | 1350w*2 |
Frequency response | 20-20KHz(+-1.5) | |
THD | <0.05 | |
S/N | >90dB | |
DF | >800db(100hz) | |
Crosstalk | >60dB | |
Slew rate | 10V/us | |
Input sensitivity | 0.775V/1.0V/1.v | |
Net Weight | 15kg | 19kg |
