◆Combined with the characteristics of the bar elements, the sound field design through the software model uses a 120-degree
wide-type waveguide to make the sound more evenly balanced. The box design uses a circular air-conducting method to make
the low-frequency more powerful and elastic, high-density paper cone. Make the sound explosive and high speed, so that the
hearing will not be tired due to the long time. In particular, the domestic custom-made high-quality speaker unit is the core component,
with smooth frequency response and precise coverage angle. The sound is crystal clear and transparent, and the space and texture
are excel lent. The crossover designed by LMS, SmaartLive and other software uses high-purity OFC oxygen-free copper inductor
wire, which minimizes the influence of the wire itself and greatly improves the power carrying capacity. Using special MKP capacitor,
the loss is very low and the internal resistance is very small. The high-power aluminum shell resistor of the enthusiast grade is adopted,
the heat dissipation speed is fast, the resistance value is accurate, and the parameter variation is smal l, which ensures excel lent
stability of sound reproduction. The frequency divider uses a fever-level scaffolding welding process to provide a powerful guarantee
for high-qual ity playback of the speaker system!
Specification
Model | T24N |
System | 3-WAY FULL RANGE |
Frequency response | 42Hz-18KHz |
Driver | LF:15"×1 |
MF :8"×1 HF:1.73"×1 | |
Nomina limpedance | 8 Ohms |
System sensitivity | 97dB |
Rated power | LF:400W HF:50W |
MF:200W | |
Peak power | LF:1600W HF:200W |
MF:800W | |
Maximum SPL | LF127dB HF137dB MF130dB |
Diffusion Angle | 50°×25° |
Crossover mode | Internal Crossover |
Installation | Multil-point suspension |
Net weight | 62KG |
Size(mm) | 530W×450D×920H |
Package size(mm) | 622w×540d×1012h |
