BASIC INFO
Description
◆It use fashionable elastic cloth in the front.
◆Sound is soft and elastic.Low frequency is ful l and natural.
◆Crossover have over-current protection to prevent from damaging tweeter.
◆Suitable for KTV,Multifunction hal l,conference.coffee hal l.
Specification
| Model | OK10B | OK102 |
| System | 2-WAY FULL RANGE | 2-WAY FULL RANGE |
| Frequency response | 50Hz-18KHz | 55Hz-18KHz |
| Driver | LF:10”×1,HF:3”×4 | LF:10”×1,HF:3”×2 |
| Rated impedance | 8 Ohms | 8 Ohms |
| Sensitivity | 95dB | 91dB |
| Rated power | 200W | 120W |
| Peak power | 400W | 240W |
| Maximum SPL | 121dB | 115dB |
| Diffusion angle（H×V） | / | / |
| Crossover mode | Inside crossovers | Inside crossovers |
| Installation | one-side suspension | one-side suspension |
| Net Weight | 10.5KG | 10.5KG |
| Product size(mm) | 520×285×315 | 503×275×313 |
| Package size(mm) | 620×385×415 | 603×375×413 |
