◆ Bui lt-in ampl ifier module.DSP based resident input module provides system
optimization and EQ functional ity.
◆ Neodymium Drive for high-power capacity and l ight-weight.
◆ Annular Ring Diaphragm HF drivers.Latest professionalcompression driver
design.
◆ Integral rigging hardware for simple connection of enclosures and optional
array frame. Dual angle pole socket for aiming flexibi l ity.
◆ Array Configuration Selector permits "array shading".
◆ 18mm plywood cabinet enclosure.Dureflex finish, which was imported,
environmental water-based paint , which can be dried in 10 seconds, no
bad smel l.
◆ The l ine array is suited for Multi-function hal l, church, wedding,Outdoor or
indoor hug, middle, smal l events.
Specification
| Model | VT4888 | VT4889 |
| System | 3-WAY Full Range | 3-WAY Full Range |
| Frequency Response | 45Hz-18KHz | 40Hz-18KHz |
| Driver | LF:2 x 12" | LF:2 x 15" |
| MF:4 x 5.5" | MF:4 x 8" | |
| HF:2 x 3" | HF:3 x 3" | |
| Power Rating | LF:1200W ,3200W Peak,8ohms | LF:2000W ,800W Peak,8 ohms |
| MF:320W 960W Peak,8 ohms | MF:140W ,560W Peak,8 ohms | |
| HF:200W,800W Peak,8 ohms | HF:240W,960W Peak,24 ohms | |
| Sensitivity(1W/1M) | LF:104dB | LF:99dB |
| MF:105ohms | MF:12ohms | |
| HF:112ohms | HF:116ohms | |
| MAX SPL | LF:131dB | LF:129dB |
| MF:133ohms | MF:138ohms | |
| HF:139ohms | HF:141ohms | |
| High-freq. disp. (H°xV°) | 90°(100M)×7.5°(150M) | 90°(100M)×7.5°(150M) |
| Dimension(HxWxD) | 946*545*378MM, 18mm Birch Plywood | 1214*546*489MM, 18mm Birch Plywood |
| Net Weight(kg) | 67KG | 67KG |
